Gas Type |
Natural
Gas or Liquid Propane
|
|
Input
BTU Rate |
NG |
Min.
25,000 - Max 235,000 |
LP |
Min.
25,000 - Max. 225,000 |
|
Thermal
Efficiency |
NG |
Max
83% |
LP |
Max.
85% |
|
Energy
Factor |
NG |
.81 |
LP |
.84 |
|
First
Hour Rating (DOE) |
300 GPH
|
|
Dimensions |
24 in.
(H) 18 in. (W) 9 in. (D)
|
|
Net
Weight |
70 lbs.
|
|
Water
Connection |
3/4 in.
NPT
|
|
Gas
Connection |
3/4 in.
NPT
|
|
Water
Pressure |
Min. 15
PSI - Max 150 PSI
|
|
Gas
Pressure |
NG |
Min.
5.0 in. wx - Max. 10.5 in. wc |
LP |
Min
11 in. wc - Max 14 in. wc |
|
Electrical
Supply |
120 V,
60 Hz with Maximum 0.8 A
|
|
Water
Flow Rate |
Min. .75
GPM - Max. 9.6 GPM
|
|
Vent |
4" Single Wall Stainless Steel
Cat. III
|
|
Installation |
Indoor
or Outdoor
|
